The S-360-24 Switching Power Supply converts AC input to a regulated 24V DC output. Operating at 360W, it drives CNC machines, LED strips, and 3D printers with a consistent 15A current. Under heavy loads, the metal casing dissipates heat to maintain stability.
Key Features
- Smart Cooling Fan: Integrated thermal sensor activates the fan only at high temperatures. Reduces internal heat during heavy road dust.
- Triple Protection Circuitry: Built-in over-voltage, over-current, and short-circuit protection prevents hardware damage. Stops electrical surges from frying components.
- Adjustable Output Voltage: Onboard potentiometer permits manual tuning within a ±10% range. Corrects voltage drops over long cables.
- 9-Screw Terminal Block: Labeled input and output terminals facilitate secure wire connections. Prevents loose contacts during high vibrations.
- 50,000-Hour MTBF: High-grade internal capacitors extend the Mean Time Between Failures. Operates reliably through BD load shedding.
Frequently Asked Questions
Can I use 24V 15A SMPS for LED strips?
This 360W unit powers up to 30 meters of standard 24V LED strips. Total wattage must stay below 300W to maintain safe overhead.
Is the S-360-24 power supply for 3D printer?
It provides the 15A current required for heated beds and stepper motors. This model replaces standard power units in Ender 3 or custom CoreXY builds.
